Fuel & Dispensing Hoses
Nitrile-tube fuel hose built to recognized fuel-handling standards for gasoline dispensers, pumps, and fuel transfer.
Need Fuel Dispensing Hose?
Share your certification requirement and size and we’ll confirm the right hose.
Send RequirementFuel-Handling Hose for Dispensers & Transfer Lines
Fuel dispensing places specific compliance and material demands on hose construction. This series uses a black nitrile tube with dual wire-helix reinforcement and a wrapped black CPE cover, built to UL330/ULC and NFPA 30A/UL30N4 (factory assemblies) standards for biodiesel, diesel, ethanol, gasoline, and oil service. It's specified for gasoline dispensers and pumps where recognized fuel-handling certification is required.
- Black nitrile tube for fuel and oil compatibility
- Dual wire-helix reinforcement for consistent bend and pressure performance
- Built to UL330/ULC and NFPA 30A/UL30N4 standards (factory assemblies)
- Operating range -40°F to +180°F (-40°C to +82°C)
- Available from 5/8″ through 1″ ID, in reel lengths
Fuel & Dispensing Hoses
Variants Available
Configurations Available
Every configuration below is confirmed against your requirement, drawing, or sample before production.
Recognized fuel-hose safety standard for dispensing applications.
Factory-assembly standard for flammable-liquid dispensing hose.
Consistent flexibility and pressure performance for dispenser duty.
Sized from 5/8-inch through 1-inch inner diameter.
Operating range suited to outdoor dispenser installations.
Cut, coupled, and pressure-tested to your specified assembly length.
Specifications
Typical Specification Inputs
Fuel dispensing hose, dual wire-helix
5/8″ through 1″
50 psi (3 bar), factory-assembly rating
Multiple textile braids with dual wire helix
Black nitrile
-40°F to +180°F (-40°C to +82°C)
UL330/ULC; NFPA 30A and UL30N4 (factory assemblies); 5:1 design factor
Matched to dispenser and pump connection requirements
Final specifications, dimensions, materials, and performance details are confirmed against approved drawings, samples, or order requirements before production.
Applications
Where This Hose Is Used
Retail and commercial fuel dispenser hose assemblies.
Pump-side fuel transfer connections at filling stations and depots.
Bulk fuel transfer at fleet and depot fueling installations.
Compatible with biodiesel (to B20), diesel, ethanol, gasoline, and oil.
Certified factory assemblies for regulated fuel-handling installations.
Cut and coupled to your specified length and end configuration.
RFQ Checklist
To Quote This Hose Accurately, We Need a Few Details
Share as much as you can — a drawing, sample, or existing part reference speeds up the process considerably.
Frequently Asked Questions
What certifications does this hose meet?
UL330/ULC, and NFPA 30A/UL30N4 for factory-assembled hose — confirm your regulatory requirement and we'll match the correct build.
What fuels is this hose compatible with?
Biodiesel (to B20 in dedicated service), diesel, ethanol, gasoline, and oil.
What sizes are available?
5/8-inch through 1-inch inner diameter, rated to 50 psi as a factory assembly.
Can this hose be used outdoors at a dispenser installation?
Yes, the operating range of -40°F to +180°F suits typical outdoor dispenser environments — confirm your climate conditions for final selection.
Do you supply factory-assembled hose only, or bulk hose too?
Both — factory-assembled, certified hose lines for dispensing installations, or bulk hose by the reel for other fuel-transfer uses.
What end fittings are available?
End fittings are matched to your dispenser or pump connection requirement, confirmed with your order.
Can Velqor support bulk export orders?
Yes, Velqor is set up for export-ready packaging and documentation. Share your destination country and quantity so we can confirm logistics.
Get Started
Ready to Source Fuel & Dispensing Hose?
Send your inner diameter, fuel type, certification requirement, and assembly length. We'll review your requirement and confirm the right hose.
