Compact & Flexible Hoses
Small-bore, low-pressure hose for paint, solvent, and light chemical transfer where flexibility and tight routing matter.
Need Compact, Flexible Hose?
Share your ID and fluid type and we’ll confirm the right hose.
Send RequirementCompact, Flexible Hose for Light-Duty Transfer
Where a connection needs to be small, flexible, and easy to route — rather than high-pressure or high-flow — this compact hose series fits. A translucent nylon tube with multiple aramid-ply reinforcement and a smooth chloroprene cover handles lacquers, light chemicals, paints, solvents, and thinners in mixing, transfer, and connector service. Working pressure ranges from 500 to 750 psi depending on size, well suited to spray equipment, dosing lines, and light process connections.
- Translucent nylon tube for chemical and solvent compatibility
- Multiple aramid-ply reinforcement for flexibility without bulk
- 500-750 psi working pressure, depending on size
- Operating range 0°F to +200°F (-18°C to +93°C)
- Available from 1/4″ through 1/2″ ID, in reel lengths
Compact & Flexible Hoses
Variants Available
Configurations Available
Every configuration below is confirmed against your requirement, drawing, or sample before production.
Smallest bore, for low-flow dosing and connector service.
Mid-range bore for general light-duty transfer lines.
Largest bore in this series, up to 750 psi working pressure.
Flexible multi-ply construction without wire bulk or weight.
Broad operating range for indoor process and spray equipment.
Cut, coupled, and pressure-tested to your specified assembly length.
Specifications
Typical Specification Inputs
Compact, flexible light-duty hose
1/4″, 3/8″, or 1/2″
500-750 psi (35-52 bar), depending on size
Multiple aramid plies
Translucent nylon
0°F to +200°F (-18°C to +93°C)
4:1 design factor
Matched to your thread standard — BSP, NPT, JIC, or metric
Final specifications, dimensions, materials, and performance details are confirmed against approved drawings, samples, or order requirements before production.
Applications
Where This Hose Is Used
Paint, lacquer, and coating transfer in spray and dosing equipment.
Light chemical, solvent, and thinner connector and transfer service.
Connector service on mixing and metering equipment.
Small-bore flexibility where space or bend radius is limited.
Light-duty fluid connections in process and testing environments.
Cut and coupled to your specified length and end configuration.
RFQ Checklist
To Quote This Hose Accurately, We Need a Few Details
Share as much as you can — a drawing, sample, or existing part reference speeds up the process considerably.
Frequently Asked Questions
What fluids is this hose compatible with?
Lacquers, light chemicals, paints, solvents, and thinners in mixing, transfer, and connector service.
What sizes are available?
1/4-inch, 3/8-inch, and 1/2-inch inner diameter, with working pressure from 500 to 750 psi depending on size.
Is this hose suitable for high-pressure service?
No — this is a light-duty, low-pressure series. For higher pressure requirements, see our general purpose or high-pressure transfer hose.
Can this hose be used outdoors?
The operating range is 0°F to +200°F — share your outdoor exposure and temperature range and we'll confirm suitability.
Do you supply cut hose or assembled/tested lengths?
Both — bulk hose by the reel, or cut, coupled, and pressure-tested assemblies to your specified length.
What end fittings are available?
End fittings are matched to your thread standard — BSP, NPT, JIC, or metric — confirmed with your hose order.
Can Velqor support bulk export orders?
Yes, Velqor is set up for export-ready packaging and documentation. Share your destination country and quantity so we can confirm logistics.
Get Started
Ready to Source Compact & Flexible Hose?
Send your inner diameter, fluid type, pressure requirement, and assembly length. We'll review your requirement and confirm the right hose and end configuration.
